SONY-SHARP BULLET CAMERA
1/3" Advanced weather proof Bullet Camera
 This very excellent COLOR OR BW camera Includes sixty feet RG6 coax cable, mounting bracket 2ea F-jack to Bnc 2ea RG6 F-jack, sixty feet 12Vdc power cable, 1ea 12Vdc plugin transformer. Excellent for use with 4 camera Dvr Pc-card or Quad processor. Can also be used as single camera connected to your vcr aux rca input to recorder. Super high resolution with high quality features provide real super clear video |
| Pickup Device: |
1/3 inch interline transfer CCD |
| Picture Element: |
TV System EIA Standard
Effective Elements 512 (H) × 492 (V) |
| Horizontal resolution: |
420 TV Lines |
| Sensitivity: |
0.01 lux/F=2.0 |
| S/N ratio: |
Over 50 dB |
| Electronic shutter: |
Iris 1/60-1/100,000 sec |
| Auto IRIS: |
dc electronic iris with fixed 4mm lens |
| Gamma Correction: |
>0.45 |
| Video output: |
1.0Vp-p, 75 ohm |
| Power source: |
Range 12V DC 100mA Max. 9~14V DC 100mA Max |
| Operating Condition |
-14° F to 122° F (-10° C to 50° C) |
- The high sensitivity of 0.01 lux/F=2.0 is achieved by using the advanced
1/3 inch interline transfer CCD.
- Minimum Illumination 0.1 lux at F2.0
- Automatic Line Lock function.
- Built-in Back Light Compensation (70% center)
- The electronic iris allow camera to be used in environment with varying light levels. Sync System Internal
- Dimensions ĝ0.75 x 2.6 inches (ĝ19mm x 66mm)
- Weight (camera only) 1.6 oz. (45g)
